Features
- Adjustable vacuum pads.
- Attach/release materials with an ON/OFF slide valve.
- Acoustic alarm system independently powered by a small 9V rechargeable battery.
- Vacuum gauge for a visual warning of low vacuum.
Specifications
- For stone, concrete, foam pads
| Metric (mm-kg) | Imperial (inch-lb) | |
| Working load limit | Pad sizes-Kg 520x125:120 520x160:180 520x220:280 520x320:500 | 20.5"x5":265 20.5"x6.3":397 20.5"x8.7":617 20.5"x12.6":1102 |
| Net weight | 21 | 46 |
| Gross weight | 26 | 57 |
| Packaging dimensions | 550x350x270 | 21.7"x13.7"x10.6" |
- Battery information for the alarm system
| Power supply | 3.7 V Lipo battery |
| Battery capacity | 2000 mAh x 1 |
| Adapter | DC 5V-1A |
| Standby time | 720 hours |
| Charging cycle | 1000 times |
| Charging time | 2 hours |
| Non-stop working time | 7 hours |
| 6-month warranty | - |
- Compressed air requirement
| Air consumption | 180 liters/minute |
| Supply air pressure | 5 bars (72 psi) |
